CMM-600
Wet/Dry Milling Machine
Aidite CMM-600 Highlights
Automatic Drying Equipped with automatic cleaning and drying functions, making cleaning easy.
Modular Structure Designed with a modular structure for efficient maintenance.
Quick-change Fixture Simple and fast with high precision.
Safety Door Opening the door during operation will stop the machine to ensure safe operation.
1, No External Air Compressor
Save procurement costs and clinic space; Simply plug in to use, easy and convenient.
2, Wet/Dry Dual-use
One machine with multiple capabilities, canprocess various materials and types.
3, Automatic Cleaning
Automatic cleaning and drying functions.
4, Spindle
Maximum Speed: 60000 RPM; Collet: 4mm.5.
5, Machine Maintenance Reminder
Intelligent reminder of equipment mainte-nance cycles and times
6, Wireless Transmission
Supports wireless data transmission.
7, High Configuration, Vertical Processing of Titanium Abutments
Smooth surface in the milling area, eliminating the need for polishing.
8, Status Indicator Three-color Light
Three colors differentiate working states for easy observation of equipment operation.
Parameter
| Machine Size | 520×724×809(mm) | |
|---|---|---|
| Machine Weight | 160kg | |
| Axis | 5 axes | |
Indications | Crown and Bridge, Inlay, Veneer, Post and Core, Implant Super structure with Full-Arch Restoration (Bridges for implant cases require a separate nesting module), Custom Abutment, Dentures | |
| Processing Method | Wet/Dry Milling | |
| Processing Materials | Zirconia, PMMA, Glass Ceramic, Composite, Tiremill, PEEK Material Specifications: 98mm Disc, Block, Premill | |
| Disc Thickness | 10-35mm | |
| Positioning Accuracy | 士5μm | |
| Transmission system | Harmonic Reducer | |
| Automatic Bur Change | Modular Bur Change, d6 Tools/Module, 4 Modules | |
Travel | XYZAxes | 200×110×90(mm) |
| B-Axis | ±180° | |
| A-Axis | 30°, +30° | |
Spindle | Power | DC500W |
| Rotation Speed | 60000rpm | |
| Collet Size | φ4 mm | |
| Input | Power Supply | Single-phase AC 220V50/60Hz Voltage |
| Power | 2.0KW 10A | |
Applications
